Descrição
| Capacitive Sensor Switch – Tipo Gamma | |||||
|---|---|---|---|---|---|
| Tamanho | Comunicação | Precisão Linear | Precisão | Precisão Fina | Roda Interna (mm) |
| 500 mm | RS485 | ±0,1% | 0,098 mm | 0,0244 mm | 100 |
| 1000 mm | 0,098 mm | 0,0244 mm | 100 | ||
| 2000 mm | 0,146 mm | 0,037 mm | 150 | ||
| 3000 mm | 0,195 mm | 0,049 mm | 200 | ||
| 4000 mm | 0,244 mm | 0,061 mm | 250 | ||
| 5000 mm | 0,244 mm | 0,061 mm | 250 | ||
| Lifetime | 5 Million x |
| Work Temperature | -20 ~ +85°C |
| Output | 3N |
| Materials | Aluminum alloy, surface anti-static interference, stainless steel pull head |
| Max Work Speed | 1m/s |
| Material Line | 49 strands of imported steel wire, outer layer nylon coating |
| Protection | IP54 |
| Absolute Digital Signal Output Type | |
|---|---|
| Interface | RS485 / CAN |
| Red | Source |
| Black | GND |
| Yellow | Z0 |
| Green | 485B / CAN H |
| White | 485A / CAN L |
| Pulse Output Type – E6B2 Rotary Encoder | |
|---|---|
| Brown | VCC |
| Black | One Phase |
| Blue | 0V |
| White | Phase B |
| Orange | Phase Z |
| Voltage Output Type (5V / 10V) | |
|---|---|
| Red | CC 12–24V |
| Black | 0V |
| Green | Production |
| Current Output Type (4–20 mA) | |
|---|---|
| Red | DC 12–24V |
| Green | Production |
